DSO Features
- DC to 2 ,1 Channel
- Sampling rate : 10MS/s
- Vertical Sensitivity : 0.1V/div~100V/div
- Horizontal Sweep : 0.2μs/div~2s/div
- Trigger : Auto and Normal
- Cursor : Δt, Δv
- Auto Setup Function
- Save/Load
DMM Features
- Auto Ranging 3 3/4 digit (3999 counts)
- True RMS
- Analog Bargraph
- Relative offset, Min./Max., dBm
Frequency counter Features
- 5?~10?, 1 Channel
- High Resolution : 5 digits
- Auto/Manual Range
|
